#!/bin/sh /etc/rc.common
# NAT6 init script for OpenWrt // Depends on package: kmod-ipt-nat6

# edited by Sad Pencil at 2020-02-09
# replace route command with ip command to solve issues on new OpenWRT


# edited by Sad Pencil at 2021-11-29
# update line WAN6_INTERFACE=$(uci get "network.$WAN6_NAME.device" || uci get "network.$WAN6_NAME.ifname")


START=55

# Options
# -------

# Use temporary addresses (IPv6 privacy extensions) for outgoing connections? Yes: 1 / No: 0
PRIVACY=1

# Maximum number of attempts before this script will stop in case no IPv6 route is available
# This limits the execution time of the IPv6 route lookup to (MAX_TRIES+1)*(MAX_TRIES/2) seconds. The default (15) equals 120 seconds.
MAX_TRIES=15

# An initial delay (in seconds) helps to avoid looking for the IPv6 network too early. Ideally, the first probe is successful.
# This would be the case if the time passed between the system log messages "Probing IPv6 route" and "Setting up NAT6" is 1 second.
DELAY=5

# Logical interface name of outbound IPv6 connection
# There should be no need to modify this, unless you changed the default network interface names
# Edit by Vincent: I never changed my default network interface names, but still I have to change the WAN6_NAME to "wan" instead of "wan6"
WAN6_NAME="wan6"

# ---------------------------------------------------
# Options end here - no need to change anything below

boot() {
        [ $DELAY -gt 0 ] && sleep $DELAY
        WAN6_INTERFACE=$(uci get "network.$WAN6_NAME.ifname")
        logger -t NAT6 "Probing IPv6 route"
        PROBE=0
        COUNT=1
        while [ $PROBE -eq 0 ]
        do
                if [ $COUNT -gt $MAX_TRIES ]
                then
                        logger -t NAT6 "Fatal error: No IPv6 route found (reached retry limit)" && exit 1
                fi
                sleep $COUNT
                COUNT=$((COUNT+1))
                PROBE=$(ip -6 route | grep -i '^default.*via' | grep -i -F "dev $WAN6_INTERFACE" | grep -i -o 'via.*' | wc -l)
        done

        logger -t NAT6 "Setting up NAT6"

        if [ -z "$WAN6_INTERFACE" ] || [ ! -e "/sys/class/net/$WAN6_INTERFACE/" ] ; then
                logger -t NAT6 "Fatal error: Lookup of $WAN6_NAME interface failed. Were the default interface names changed?" && exit 1
        fi
        #WAN6_GATEWAY=$(ip -6 route | grep -o '2001.*1102' | sed s'/1102/1101::1/g')
        WAN6_GATEWAY=$(ip -6 route | grep -i '^default.*via' | grep -i -F "dev $WAN6_INTERFACE" | grep -i -o 'via.*' | cut -d ' ' -f 2 | head -n 1)
        if [ -z "$WAN6_GATEWAY" ] ; then
                logger -t NAT6 "Fatal error: No IPv6 gateway for $WAN6_INTERFACE found" && exit 1
        fi
        LAN_ULA_PREFIX=$(uci get network.globals.ula_prefix)
        if [ $(echo "$LAN_ULA_PREFIX" | grep -c -E "^([0-9a-fA-F]{4}):([0-9a-fA-F]{0,4}):") -ne 1 ] ; then
                logger -t NAT6 "Fatal error: IPv6 ULA prefix $LAN_ULA_PREFIX seems invalid. Please verify that a prefix is set and valid." && exit 1
        fi

        ip6tables -t nat -I POSTROUTING -s "$LAN_ULA_PREFIX" -o "$WAN6_INTERFACE" -j MASQUERADE
        if [ $? -eq 0 ] ; then
                logger -t NAT6 "Added IPv6 masquerading rule to the firewall (Src: $LAN_ULA_PREFIX - Dst: $WAN6_INTERFACE)"
        else
                logger -t NAT6 "Fatal error: Failed to add IPv6 masquerading rule to the firewall (Src: $LAN_ULA_PREFIX - Dst: $WAN6_INTERFACE)" && exit 1
        fi

        ip -6 route add 2000::/3 via "$WAN6_GATEWAY" dev "$WAN6_INTERFACE"
        if [ $? -eq 0 ] ; then
                logger -t NAT6 "Added $WAN6_GATEWAY to routing table as gateway on $WAN6_INTERFACE for outgoing connections"
        else
                logger -t NAT6 "Error: Failed to add $WAN6_GATEWAY to routing table as gateway on $WAN6_INTERFACE for outgoing connections"
        fi

        if [ $PRIVACY -eq 1 ] ; then
                echo 2 > "/proc/sys/net/ipv6/conf/$WAN6_INTERFACE/accept_ra"
                if [ $? -eq 0 ] ; then
                        logger -t NAT6 "Accepting router advertisements on $WAN6_INTERFACE even if forwarding is enabled (required for temporary addresses)"
                else
                        logger -t NAT6 "Error: Failed to change router advertisements accept policy on $WAN6_INTERFACE (required for temporary addresses)"
                fi
                echo 2 > "/proc/sys/net/ipv6/conf/$WAN6_INTERFACE/use_tempaddr"
                if [ $? -eq 0 ] ; then
                        logger -t NAT6 "Using temporary addresses for outgoing connections on interface $WAN6_INTERFACE"
                else
                        logger -t NAT6 "Error: Failed to enable temporary addresses for outgoing connections on interface $WAN6_INTERFACE"
                fi
        fi

        exit 0
}

  1
  2
  3
  4
  5
  6
  7
  8
  9
 10
 11
 12
 13
 14
 15
 16
 17
 18
 19
 20
 21
 22
 23
 24
 25
 26
 27
 28
 29
 30
 31
 32
 33
 34
 35
 36
 37
 38
 39
 40
 41
 42
 43
 44
 45
 46
 47
 48
 49
 50
 51
 52
 53
 54
 55
 56
 57
 58
 59
 60
 61
 62
 63
 64
 65
 66
 67
 68
 69
 70
 71
 72
 73
 74
 75
 76
 77
 78
 79
 80
 81
 82
 83
 84
 85
 86
 87
 88
 89
 90
 91
 92
 93
 94
 95
 96
 97
 98
 99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156
157
158
159
160
161
162
163
164
165
166
167
168
169
170
171
172
173
174
175
176
177
178
179
180
181
182
183

# Powered by luoboQAQ
log:
  level: warn
  file: "/tmp/log/mosdns.log"

# API 入口设置
api:
  http: "0.0.0.0:9091"

plugins:
  # 国内域名
  - tag: geosite_cn
    type: domain_set
    args:
      files:
        - "/var/mosdns/direct-list.txt"

  # 国内IP
  - tag: geoip_cn
    type: ip_set
    args:
      files:
        - "/var/mosdns/CN-ip-cidr.txt"

  # 国外域名
  - tag: geosite_no_cn
    type: domain_set
    args:
      files:
        - "/var/mosdns/proxy-list.txt"

  # 黑名单域名
  - tag: blocklist
    type: domain_set
    args:
      files:
        - "/etc/mosdns/rule/blocklist.txt"

  # 广告域名
  - tag: adlist
    type: domain_set
    args:
      files:
        - "/var/mosdns/ad-domains.txt"

  # PTR黑名单
  - tag: local_ptr
    type: domain_set
    args:
      files:
        - "/etc/mosdns/rule/local-ptr.txt"

  # 缓存插件
  - tag: cache
    type: cache
    args:
      size: 10240
      lazy_cache_ttl: 86400
      # 将缓存保存在磁盘
      dump_file: /tmp/mosdns/cache.dump

  # 转发至本地服务器的插件
  - tag: forward_local
    type: forward
    args:
      upstreams:
        - tag: alidns_dot
          addr: "tls://223.5.5.5"
        - tag: dnspod_dot
          addr: "tls://120.53.53.53"

  # 转发至远程服务器的插件
  - tag: forward_remote
    type: forward
    args:
      upstreams:
        # - tag: easymosdns
        #   addr: "https://doh.apad.pro/dns-query"
        #   bootstrap: "223.5.5.5"
        - tag: cloudflare_dot
          addr: "tls://1.1.1.1"

  # 国内解析
  - tag: local_sequence
    type: sequence
    args:
      - exec: $forward_local

  # fallback 用本地服务器 sequence
  # 返回不包含本地 ip 则 reject
  - tag: local_ip_sequence
    type: sequence
    args:
      - exec: $forward_local
      - matches: "!resp_ip $geoip_cn"
        exec: drop_resp

  # fallback 用远程服务器 sequence
  - tag: remote_sequence
    type: sequence
    args:
      - exec: $forward_remote

  # fallback插件
  - tag: fallback
    type: fallback
    args:
      primary: local_ip_sequence
      secondary: remote_sequence
      threshold: 500
      always_standby: true

  # 有响应终止返回
  - tag: has_resp_sequence
    type: sequence
    args:
      - matches: has_resp
        exec: accept

  # 查询国内域名
  - tag: query_is_local_domain
    type: sequence
    args:
      - matches: qname $geosite_cn
        exec: $local_sequence

  # 查询国外域名
  - tag: query_is_no_local_domain
    type: sequence
    args:
      - matches: qname $geosite_no_cn
        exec: $remote_sequence

  # 查询拒绝域名
  - tag: query_is_reject_domain
    type: sequence
    args:
      - matches: qname $blocklist
        exec: reject 3
      - matches: qname $adlist
        exec: reject 3
      - matches:
        - qtype 12
        - qname $local_ptr
        exec: reject 3
      - matches: qtype 65
        exec: reject 3

  # 主要运行逻辑插件
  - tag: main_sequence
    type: sequence
    args:
      # 去广告
      - exec: $query_is_reject_domain
      - exec: jump has_resp_sequence

      # ipv4地址优先，避免NAT占用CPU
      - exec: prefer_ipv4

      - exec: $cache
      - exec: jump has_resp_sequence

      - exec: $query_is_local_domain
      - exec: jump has_resp_sequence

      - exec: $query_is_no_local_domain
      - exec: jump has_resp_sequence

      - exec: $fallback

  # 启动 udp 服务器。
  - tag: udp_server
    type: udp_server
    args:
      entry: main_sequence
      listen: ":5335"

  # 启动 tcp 服务器。
  - tag: tcp_server
    type: tcp_server
    args:
      entry: main_sequence
      listen: ":5335"
